DC Power Control Extension
The DC Power Control extension enables power management for connected DC-powered devices, such as mini PCs or NAS units.
Not compatible with JetKVM MiniUse it with JetKVM. USB versions for the Mini come in a later release.
Buy from an authorized reseller
Ships to 40+ countriesPricing varies by region
Remote Power Control for any DC device
Add remote power cycling to your JetKVM setup. Connect it to the extension port, route your device's DC power through the module, and control power directly from the browser with the JetKVM.
It supports DC input ranging from 12 to 20 volts, and we're including adapters to support 5.5x2.1 mm connections as well.
The extension can also power the JetKVM itself through the extension cable, streamlining setup and reducing the need for additional power sources.
Pass-through Power
Plug 5V into the extension's USB-C port and it powers your JetKVM over the extension cable, without a separate USB connection.
This eliminates the need for constant USB power from the host computer or a USB splitter, simplifying your setup with a single-cable solution for both power and control.
Specifications
Electrical and Operating Requirements
- Voltage
- 9-20V DC Max 5A
- Barrel polarity
- Center Positive
- Frequency
- 50Hz to 60Hz, single phase
- Operating temperature
- 10-35°C (50-95°F)
- Storage temperature
- 0-47°C (-32-116°F)
- Relative humidity
- 5-90% non-condensing
Resources
In the box
DC Extension
Main extension hardware unit with protective case
5-pin to RJ12 cable
5-pin end into the JetKVM, RJ12 end into the extension
1x 5.5/2.5 mm male to 5.5/2.5 mm male cable
DC power connection cable
User Manual
Complete setup and usage guide
